| OPERATIONAL |
: |
Light Source 650 nm + 10 nm VLD Laser Power Less than 1 mW (peak) Decode Capability Autodiscriminates all standard 1D bar codes including GS1 DataBarTM; for others call a Metrologic service representative System Interfaces RS232/Light Pen, PC Keyboard Wedge, Stand-Alone Keyboard, USB, IBM 468X/469X Number Characters Read Up to 80 data characters Beeper Operation 7 tones or no beep Indicators (LED)
Blue Steady = unit powered, ready to scan, Bluetooth connected; White = good read; Yellow Steady = battery full; Yellow Blinking = battery charging |
| SCAN PERFORMANCE |
: |
Depth of Scan Field (programmable) 0 mm - 229 mm (0” - 9”) for 0.330 mm (13 mil) bar
codes @ default Width of Scan Field 64 mm (2.5”) @ face; 272 mm (10.7”) @ 229 mm (9”)
Scan Speed 100 scan lines per second + 2 Scan Pattern Single scan line Minimum Bar Width 0.102 mm (4 mil) Print Contrast 35% minimum reflectance difference Roll, Pitch, Yaw 42°, 68°, 52° |
